Solid Strut Channel is a structural support member distinct from its slotted counterpart, characterized by a completely smooth, unperforated web typically fabricated from steel or aluminum. Unlike traditional strut channel, its solid design eliminates mounting holes, providing a continuous and uniform surface.
The key function of the Solid Strut Channel is to deliver superior load-bearing strength and maximum resistance to bending and torsional forces across its entire length. It acts as a pure structural element, perfect for use as a strong edge trim, a solid frame rail in heavy-duty shelving and industrial platforms, or a rigid member in machinery guards where traditional bolt-on accessories are not required.
| Item | P/N | Length | Size WXH | Hole Spacing Center to Center | Hole diameter | Thickness | Material | Finishes Option | Weight | Standard Pack |
| Solid Strut Channel | HHUCP41310 | 3.05m | 1-5/8" X 1-5/8" 41mm X 41mm | 2"/50.8mm | 14mmX28mm | 1.0 mm | ASTM A570/Q235 Stainless Steel | Pregalvanized Hot Dip Galvanized Powder coat | 3.1KG | 50pc/bundle |
| HHUCP41315 | 2"/50.8mm | 14mmX28mm | 1.5 mm | 4.7KG | 50pc/bundle | |||||
| HHUCP41320 | 2"/50.8mm | 14mmX28mm | 2.0 mm | 6.3KG | 50pc/bundle | |||||
| HHUCP41325 | 2"/50.8mm | 14mmX28mm | 2.5 mm | 7.9KG | 50pc/bundle | |||||
| HHUCP41610 | 6.09m | 1-5/8" X 1-5/8" 41mm X 41mm | 2"/50.8mm | 14mmX28mm | 1.0 mm | ASTM A570/Q235 Stainless Steel | Pregalvanized Hot Dip Galvanized Powder coat | 6.3KG | 50pc/bundle | |
| HHUCP41615 | 2"/50.8mm | 14mmX28mm | 1.5 mm | 9.5KG | 50pc/bundle | |||||
| HHUCP41620 | 2"/50.8mm | 14mmX28mm | 2.0 mm | 12.7KG | 50pc/bundle | |||||
| HHUCP41625 | 2"/50.8mm | 14mmX28mm | 2.5 mm | 15.9KG | 50pc/bundle | |||||
| HHUCP21310 | 3.05m | 1-5/8" X 13/16" 41mm X 21mm | 2"/50.8mm | 14mmX28mm | 1.0 mm | ASTM A570/Q235 Stainless Steel | Pregalvanized Hot Dip Galvanized Powder coat | 2.2KG | 50pc/bundle | |
| HHUCP21315 | 2"/50.8mm | 14mmX28mm | 1.5 mm | 3.3KG | 50pc/bundle | |||||
| HHUCP21320 | 2"/50.8mm | 14mmX28mm | 2.0 mm | 4.4KG | 50pc/bundle | |||||
| HHUCP21325 | 2"/50.8mm | 14mmX28mm | 2.5 mm | 5.6KG | 50pc/bundle | |||||
| HHUCP21610 | 6.09m | 1-5/8" X 13/16" 41mm X 21mm | 2"/50.8mm | 14mmX28mm | 1.0 mm | ASTM A570/Q235 Stainless Steel | Pregalvanized Hot Dip Galvanized Powder coat | 4.5KG | 50pc/bundle | |
| HHUCP21615 | 2"/50.8mm | 14mmX28mm | 1.5 mm | 6.7KG | 50pc/bundle | |||||
| HHUCP21620 | 2"/50.8mm | 14mmX28mm | 2.0 mm | 8.9KG | 50pc/bundle | |||||
| HHUCP21625 | 2"/50.8mm | 14mmX28mm | 2.5 mm | 11.2KG | 50pc/bundle |
Unperforated Design: The primary feature of the Solid Strut Channel is its smooth, unperforated web, which lacks the keyhole slots found in standard strut channels, providing a continuous surface.
Material and Construction: It is typically fabricated from formed steel or aluminum, prioritizing structural integrity through a consistent and uninterrupted profile.
Pure Structural Function: The design focuses solely on delivering maximum strength, without accommodations for bolt-on accessories or attachments.
Superior Strength and Rigidity: The Solid Strut Channel offers exceptional load-bearing capacity and resistance to bending and torsion, ideal for long-span supports and heavy-duty applications.
Enhanced Safety: Its solid web eliminates snag or pinch points, improving safety for personnel and protecting cables or wiring.
Clean Aesthetic: The absence of perforations provides a neat, finished appearance, making it suitable for applications where visual appeal is important.
Please complete the form. Our experts will contact you to provide a tailored solution and technical specifications for your project needs.
